High Pressure Regulators

Designed for accurate pressure regulation with low capacities. It is ideal for residential, commercial and industrial heating and portable equipment.

• Maximum Inlet Pressure: 250 PSI
• Outlet Pressure Range: 3″WC – 5 PSI
• Size Range: 1/4″ & 1/4″x 3/8″ NPT
• Approvals: UL-144 (certain configurations)

Designed for pressure regulation of gas or liquid applications. Handwheel operated is standard but has the option of a fixed tamper-proof spring case.

• Maximum Inlet Pressure: 250 PSI
• Outlet Pressure Range: 3 – 100 PSI
• Size Range: 1/4″ NPT
• Approvals: UL-144

Designed for accurate pressure regulation in both natural gas and propane gas applications in a compact size. They are ideal for first stage and heating equipment requiring high pressures.

• Maximum Inlet Pressure: 250 – 400 PSI
• Outlet Pressure Range: 3 – 125 PSI
• Size Range: 1/2″ – 1″ NPT
• Approvals: UL-252

Designed for highly accurate pressure reduction for industrial use. Trim materials avaialble for standard, high tempreture and NH3 applications.

• Maximum Inlet Pressure: 250 PSI
• Outlet Pressure Range: 3 – 125 PSI
• Size Range: 1/2″ – 1″ NPT
• Approvals: UL-144

Designed for high capacity as a first stage regulator. Options also include internal relief valve, high temperature, and monitor configurations.

• Maximum Inlet Pressure: 250 – 1,000 PSI
• Outlet Pressure Range: 5 – 150 PSI
• Size Range: 3/4″ – 2″ NPT
• Approvals: UL-144 (certain configurations)

Designed for high capacity as a first stage regulator for industrial applications.

• Maximum Inlet Pressure: 250 – 1,500 PSI
• Outlet Pressure Range: 3 – 40 PSI
• Size Range: 2″ NPT

Designed with a variety of options in materials and pressures for any application. Iron or steel, internal relief valve and high pressure outlets up to 500 PSI are available.

• Maximum Inlet Pressure: 250 – 2,000 PSI
• Outlet Pressure Range: 5 – 500 PSI
• Size Range: 1″ & 2″ NPT, 1″ & 2″ Flanged
• Approvals: CRN

Designed for heavy duty applications. All cast iron construction with stainless steel trim as standard. Steel construction and viton diaphragm also available for high temperatures.

• Maximum Inlet Pressure: 250 – 1,500 PSI
• Outlet Pressure Range: 3 – 500 PSI
• Size Range: 1″ & 2″ NPT, 1″ & 2″ Flanged
• Approvals: CRN

Designed for industrial process in a compact, direct acting design. Ideal for liquids as well as steam and gas applications.

• Maximum Inlet Pressure: 300 PSI
• Outlet Pressure Range: 15 – 150 PSI
• Size Range: 3/4″ – 1″ NPT
• Approvals: CRN

Designed for first cut low flow pressure reductions. Ideal for valve actuators, catalytic heaterspressure controls and chemical injection pumps. Brass construction.

• Maximum Inlet Pressure: 5,500 PSI
• Outlet Pressure Range: 3 – 225 PSI
• Size Range: 1/4″ NPT

Designed for first cut low flow pressure reductions. Ideal for valve actuators, catalytic heaterspressure controls and chemical injection pumps. All stainless steel construction.

• Maximum Inlet Pressure: 6,000 PSI
• Outlet Pressure Range: 10 – 500 PSI
• Size Range: 1/4″ NPT
• Approvals: CRN

Designed for accurate pressure reduction which includes a integral filter as standard. Ideal for instrumentation and general purpose applications.

• Maximum Inlet Pressure: 250 PSI
• Outlet Pressure Range: 3 – 125 PSI
• Size Range: 1/4″ NPT
• Approvals: CRN
